F-Series Vastex Flash Unit

Contact us at 1-800-663-4657 to order

Current stock: 0
Description

Description

High wattage and close coil density heater, for greater heater surface consistency.

Powerful heaters with built-in heat shields allow Vastex flashes to be set closer to your garment, which increases efficiency and productivity.

F-100
Entry Level Flash Cure Unit


  • 15 Year Heater Warranty
  • 1,625 Watt IR Heater
  • On/off power switch
  • Heavy duty side handles
  • Head leveler to adjust the heater parallel
    to the pallet
  • Heat shields for even heater temperature



F-1000
Mid Level Flash Cure Unit


  • 15 Year Heater Warranty
  • 1,950 Watt IR Heater
  • Heat control with power lights
  • Heavy duty side handles and locking wheels
  • Head leveler to adjust the heater parallel
    to the pallet
  • Heat shields for even heater temperature

F-100 AND F-1000 OPTIONS

Auto-Flash
Rotates flash cure head automatically

 Optional on F-100 and F-1000 Flash Cure units is an Auto-Flash upgrade that rotates the head into place above the pallet of a screen printing press with the touch of a foot pedal, and automatically rotates the head away from the pallet after a user-adjustable dwell time has elapsed. The AutoFlash unit provides an accurate and repeatable amount of time to flash your garment. Both overflashing and underflashing is a problem many people overlook in this important process.

Rotary Pallet Adapter
Allows drying as well as flash curing

The Dual Rotary Pallet Adapter option allows you to additionally use an F-100 and F-1000 Flash Cure Unit as a low cost dryer. After loading a garment on one of the ventilated steel pallets, simply rotate it into the heater zone. Load another garment onto the other ventilated pallet and, when the first garment has cured, rotate the adapter 180° to cure the next garment, and so on. Remove one pallet within seconds and you can flash and cure with the same unit by swinging the head.



TECHNICAL SPECIFICATIONSF-100 logoF-1000 logo
Heater Warranty 15 Year 15 Year
Bumper to Bumper Warranty 3 Year 3 Year
Heater Size 16" x 16" (41 x 41 cm) 18" x 18" (46 x 46 cm)
Unit Warm Up Time 15 min. (120V) or 10 min. (240V) 20 min. (120V) or 10 min (240V)
Electrical Specs* / included plug
(Some models require a dedicated line.
50/60 HZ for all units.)
120V/13A/1625W
NEMA 5-15P

240V/6.5A/1625W
NEMA 6-15P
120V/15.6/1950W
NEMA 5-20P

240V/7.8A/1950W
NEMA 6-15P
Electrical Specs - Auto-Flash / included plug 110-125V/1A
NEMA 5-15P

220-240V/1A
NEMA 6-15P
110-125V/1A
NEMA 5-15P

220-240V/1A
NEMA 6-15P
Weight** 39 lbs (18 kg) 42 lbs (19 kg)
Dimensions** 23" x 28" x 9" (58 x 71 x 22.9 cm) 23" x 28" x 9" (58 x 71 x 22.9 cm)
